IoT Nodes

Modular, stackable nodes that speak any protocol.

Ion

Ion is one of our all-in-one IoT nodes — a compact, customisable connected device that collects data about its environment and forwards it to your applications over whichever radio makes sense for the job.

Ion is connection-agnostic. From LoRaWAN to Bluetooth LE, Wi-Fi, cellular (LTE-M / NB-IoT), Sigfox, Zigbee and beyond — we support just about every protocol, and the radio module is part of the stack, so it can be swapped or added later without replacing the device.

Ion is built to be stackable: its functionality is expanded by clipping additional modules onto the core unit. Extra sensors, I/O, power options, and interface boards share the same enclosure and stack, so a single Ion can be tailored to almost any deployment — and upgraded later in the field.

Ion integrates with third-party hardware and sensors, giving it the freedom to be deployed virtually anywhere. Once connected, the data stream can be directed to the cloud, SCADA, mobile devices or web platforms — from dense urban networks to rural sites where conventional infrastructure is limited or unavailable.

Ion IoT node - exploded component view
All-in-one IoT node
Stackable expansion modules
Modular sensor & I/O add-ons
Field-upgradeable
GPS positioning
Small form factor
Optionally solar powered
Variety of enclosure designs
Multi-protocol radio
LoRaWAN / BLE / Wi-Fi / Cellular
Network-independent options
2+ year battery (active reporting)
5+ year battery (passive mode)
Movement activation
Built-in activity meter
Temperature sensor (-40 to 85°C)
3 additional sensor inputs (max 3V6)

Ideal For

Asset tracking
Environment data gathering
Security
Fridge/Freezer temperature monitoring
Point-of-interest activity
Measuring anything digitisable
Specification Detail
ProtocolsLoRaWAN, Bluetooth LE, Wi-Fi, Cellular (LTE-M / NB-IoT), Sigfox, Zigbee, Modbus — and more on request
LoRaWAN frequencies433 MHz, 868 MHz, 913 MHz (where applicable)
LocalisationGPS, cell-tower & Wi-Fi positioning
Battery (active reporting)2+ years @ 1 update/day
Battery (passive)5+ years
Power optionsBattery, solar, or 5–24 V external
Temperature range-40°C to 85°C
Sensor inputs3 (max input 3V6)

Connectivity

Pick the right radio for the job — we support just about every protocol.

LoRaWAN
LoRaWAN
Bluetooth LE
Wi-Fi

Plus Cellular (LTE-M / NB-IoT), Sigfox, Zigbee, Z-Wave, Thread, Ethernet, Modbus — and most others on request.

Platform

Once captured, your data is delivered wherever it needs to go — cloud, control rooms, mobile, or web.

Cloud
Stream telemetry to managed cloud endpoints & dashboards.
SCADA
Bridge directly into industrial control & monitoring systems.
Mobile
Native iOS & Android apps for on-the-go visibility.
Web
Custom web dashboards & APIs tailored to your workflow.

Get Started

Start exploring possibilities with a customisable demo unit. We'll match the radio to your site — whether that's LoRaWAN over The Things Network, cellular, Wi-Fi, or something else entirely.

Request a Demo
